Digital Electronic Photocontrol ANSI C136.10 Twist Lock Zero Cross Technology Inside

Brand Name : LongJoin

Model Number : JL-207

Place of Origin : China

Price : negotiable

Packaging Details : Different packaging methods are adopted according to different modes of transport.

Payment Terms : Western Union,MoneyGram,T/T

Rate Voltage : 120~277VAC(207C) / 347VAC(207E) / 480VAC(207F)

Power consumption : 0.5W Max.(207C) / 0.9W Max.(207E) / 0.5W Max.(207F)

Factory settings : Illuminance/Delayed Customizable

Operate Levels : 16Lx On / 24Lx Off （Typical）

Certifications : RoHS,UL,CE

Real-world Scenarios : Smart City Pilot Projects

Contact Now

Digital Electronic Photocontrol ANSI C136.10 Twist Lock Zero Cross Technology Inside
Product Overview

The JL-207 Digital Electronic Photocontrol series automatically controls street lighting, garden lighting, passage lighting, and doorway lighting based on ambient natural light levels, featuring energy-saving operation at dawn.

Designed with microprocessor circuits, IR-filtered phototransistor, and built-in surge arrester (MOV), this product includes a preset 5-20 second time-delay to prevent redundant operation from spotlights or lightning during nighttime.

The long-life version maintains constant and reliable characteristics with over 10,000 working life cycles. The optional double-layer protective shell extends working life, while the HP version supports higher loads.

Features twist-lock terminals compliant with ANSI C136.10 and ANSI/UL773 standards for plug-in, locking type photocontrols used with area lighting.

Product Dimensions
Digital Electronic Photocontrol ANSI C136.10 Twist Lock Zero Cross Technology Inside
Key Features
  • ANSI C136.10 Twist Lock compatibility
  • Fully customizable configurations available
  • Built-in surge arrester for protection
  • IR-filtered phototransistor for accurate sensing
  • Fail-On / Fail-Off modes available
  • UV stabilized enclosure for durability
  • Midnight sleeping functionality
  • Zero-Cross Technology for stable operation
  • Supports FCC Class A / Class C requirements
Technical Specifications
Model No. JL-207C JL-207CHP JL-207E JL-207F
Rate Voltage 120~277VAC 347VAC 480VAC
Applicable Voltage Range 105~305VAC 105~382VAC 105~528VAC
Rated Voltage 50/60Hz
Related Humidity 96%
Ambient Temperature -40℃~+70℃
Failure Mode C5:Fail-On C4:Fail-Off C5HP:Fail-On C4HP:Fail-Off E5:Fail-On E4:Fail-Off F5:Fail-On F4:Fail-Off
Rated Loading 1000W Tungsten, 1800VA Ballast, 8A@120VAC/5A@208-277VAC e-Ballast 1800W@120VAC 2000W@208-277VAC Tungsten, 1800VA@120VAC 2000VA@208-277VAC Ballast 1800W Tungsten, 1800VA Ballast, 5A e-Ballast 1800W Tungsten, 1800VA Ballast
Operate Levels 16Lx On / 24Lx Off (Typical)
Shell Material Optional Sandwich cover
Power Consumption 0.5W Max. 0.9W Max. 0.5W Max.
High Protection Sandwich cover (optional)
IP Level IP54 / IP65 / IP67
Factory Settings Illuminance/Delayed Customizable
Zero Crossing Control ● N/A ● ●
FCC ● N/A ● ●
Certifications Digital Electronic Photocontrol ANSI C136.10 Twist Lock Zero Cross Technology InsideDigital Electronic Photocontrol ANSI C136.10 Twist Lock Zero Cross Technology Inside ANSI C136.10-2017 Digital Electronic Photocontrol ANSI C136.10 Twist Lock Zero Cross Technology InsideDigital Electronic Photocontrol ANSI C136.10 Twist Lock Zero Cross Technology Inside Digital Electronic Photocontrol ANSI C136.10 Twist Lock Zero Cross Technology InsideDigital Electronic Photocontrol ANSI C136.10 Twist Lock Zero Cross Technology Inside Digital Electronic Photocontrol ANSI C136.10 Twist Lock Zero Cross Technology InsideDigital Electronic Photocontrol ANSI C136.10 Twist Lock Zero Cross Technology Inside
Frequently Asked Questions
What standard does this digital electronic photocontrol comply with?
It complies with the ANSI C136.10 standard for photocontrol devices.
What mounting type does this photocontrol adopt?
It uses twist-lock mounting for easy installation and replacement.
What key technology is built inside this photocontrol?
It is equipped with zero cross technology inside for stable and safe operation.
What type of product is this photocontrol?
It is a digital electronic photocontrol used for automatic street light control.
What are the benefits of zero cross technology in this photocontrol?
It reduces switching surge, protects lamps and drivers, and extends service life.
